Items Description
Fitments:
- For 2003-2015 Ford Expedition
- For 2006-2014 Ford F150 Truck
- For 2006-2014 Lincoln Mark LT
- For 2003-2015 Lincoln Navigator
- For 2004-2011 Ford Lobo
Place on Vehicle: Front Left (Driver) or Right (Passenger)Side (Come as a pcs)
Replacement OEM Number: 5L1Z3C247A, 7L1Z3C247A, 7L1Z-3C247-A., 600-105,SW9320,2L1Z3C247AA
Feature:
- Direct replacement
- Built to strict quality control standards
Package Include
- 1 piece
Installation Instructions
STEP 1: RAISE AND SECURE THE VEHICLE
- Raise the vehicle with a jack
- Secure the vehicle on jack stands
STEP 2: REMOVING THE CV AXLE SHAFT
- Pry off the wheel center cap with a flat blade screwdriver
- Remove the cap over the hub nut
- Remove the 13mm hub nut
- While holding the tire in place, remove the six twelve-point 12mm bolts from the CV joint
- Remove the 30mm bolt from the strut assembly using a breaker bar or ratchet and pipe
- Tap the nut with a hammer to loosen it, if necessary
- Pry the lower end of the strut assembly from the lower control arm with a pry bar
- Pull out the CV shaft
STEP 3: REMOVING THE FOUR WHEEL DRIVE ACTUATOR
- Remove the three 8mm bolts from the four wheel drive actuator
- Pry off the actuator with a flat blade screwdriver
- Disconnect the vacuum hoses from the actuator
STEP 4: INSTALLING THE NEW ACTUATOR
- Connect the vacuum hoses to the new actuator
- Put the actuator into place
- Start the three 8mm bolts by hand
- Tighten the three 8mm bolts
STEP 5: REATTACHING THE CV AXLE
- Slide the CV Axle back into place
- Reconnect the strut at the lower control arm
- Push the bolt through where the strut connects to the lower control arm
- Attach the nut
- Tighten the bolt to between 95-100 foot-pounds of torque
- Start the 12-point 12mm bolts into the CV axle by hand
- Tighten the bolts preliminarily
- Tighten the bolts to 25 foot-pounds in a crossing or star pattern
- Reinstall the 13mm nut on the end of the axle
- Reinstall the cap over the nut
- Reinstall the center cap
- Lower the vehicle
