Rear Wheel Bearing for 2011-2017 Nissan Juke, 2011 2012 Leaf Wheel Hub, 5 Lugs, 2WD FWD-512494

Rear Wheel Bearing for 2011-2017 Nissan Juke, 2011 2012 Leaf Wheel Hub, 5 Lugs, 2WD FWD-512494

Fit the Following Vehicles:
2011 2012 2013 2014 2015 2016 2017 Nissan Juke (FWD Models Only)
2011 2012 Nissan Leaf (FWD Models Only)

Specifics:
Position:Driver(LH Left) or Passenger(RH Right) Side Rear
ABS Sensor Included: No
Number Of Mounting Bolts To Knuckle: 4
Number Of Flange Bolts Included: 5
Driven Or Non-Driven: Non-Driven
ABS Ring Type: Magnetic
Number Of ABS Sensor Ring Teeth: 96
ABS Sensor Ring Diameter (in): 2.669 Inch
Total Hub Diameter (in): 5.8268 Inch
Hub Centerbore Diameter (in): 4.5 Inch
Total Hub Height (in): 4.9606 Inch
Flange Diameter (in): 5.8268 Inch
Flange Offset (in): 2.7165 Inch
Flange Bolt Size (in): 1.189 Inch
Hub Pilot Diameter (in): 2.5984 Inch
Flange Bolt Thread Size: M12-1.25
