Front Wheel Bearing Fit Cadillac Escalade,Chevrolet K1500 K2500 Suburban, Tahoe, GMC K1500 K2500 Suburban, Wheel Hub w/ABS 6 Lugs, 4WD-515024 (2 Pack)
Front Wheel Bearing Fit Cadillac Escalade,Chevrolet K1500 K2500 Suburban, Tahoe, GMC K1500 K2500 Suburban, Wheel Hub w/ABS 6 Lugs, 4WD-515024 (2 Pack)
Fit:
1999 2000 Cadillac Escalade
1995 1996 1997 1998 1999 Chevrolet K1500 Pickup
1995 Chevrolet K2500 Pickup
1995 1996 1997 1998 1999 Chevrolet K1500 Suburban
1995 Chevrolet K2500 Suburban
1995 1996 1997 1998 1999 2000 Chevrolet Tahoe
1995 1996 1997 1998 1999 GMC K1500 Pickup
1995 1996 1997 1998 1999 GMC K1500 Suburban
1995 GMC K2500 Pickup
1995 GMC K2500 Suburban
1995 1996 1997 1998 1999 2000 GMC Yukon
Description:
Position:Driver(LH Left) or Passenger(RH Right) Side Front
ABS Sensor Included: Yes
Wiring Harness Included: Yes
Number Of Lug Bolts Included: 6
Driven Or Non-Driven: Driven
ABS Ring Type: Tone
Material: Steel
Number Of Mounting Bolts To Knuckle: 3
Number Of Splines: 33
Number Of ABS Sensor Ring Teeth: 55
Total Hub Diameter (in): 7.125 Inch
Hub Centerbore Diameter (in): 5.5 Inch
Total Hub Height (in): 4.622 Inch
Flange Diameter (in): 7.161 Inch
Flange Offset (in): 2.232 Inch
Total Hub Diameter (mm): 181mm
Hub Centerbore Diameter (mm): 139.7mm
Total Hub Height (mm): 117.4mm
Flange Diameter (mm): 181.9mm
Flange Offset (mm): 56.7mm
Flange Bolt Size (in): 1.354 Inch
Flange Bolt Size (mm): 34.4mm
Hub Pilot Diameter (in): 3.082 Inch
Hub Pilot Diameter (mm): 78.3mm
Inner Ring Width (in): 0.94 Inch
Outer Ring Width (in): 2.12 Inch
Lug Bolt Thread Size: M14-1.50
