GMC Jimmy Front Wheel Bearing Hub Assembly 1997-2005, 513124
Regular price
$89.00
Regular price
$99.00
-10%
Sale price
$89.00
Front Wheel Bearing Fit Chevy Blazer, Chevy S10, GMC Jimmy, GMC Sonoma, Isuzu Hombre, Oldsmobile Bravada Wheel Hub-5 Lug W/ABS, 513124 (2 Pack)
Front wheel bearing with ABS sensor and wiring harness. Fits multiple Chevy, GMC, Isuzu, and Oldsmobile models. Durable steel construction with ball bearing design.
What's Included
- 2 x Front Wheel Bearings (Driver and Passenger Side)
- ABS Sensor Included
- Wiring Harness (32.25 Inch)
- 5 Lug Bolts Included
Product Specifications
- Position: Driver (LH) or Passenger (RH) Side Front
- ABS Connector Shape: Oval
- Mounting Bolts to Knuckle: 3
- Number of Splines: 27
- Lug Bolt Thread Size: M12-1.50
- Total Hub Diameter: 5.68 Inch
- Total Hub Height: 4.30 Inch
- Flange Diameter: 5.68 Inch
- Flange Offset: 1.85 Inch (46.99mm)
- Hub Pilot Diameter: 3.61 Inch
- Flange Shape: Triangle
- Flange Bolt Thread Size: M12-1.75
- Material: Steel
- Bearing Type: Ball
Vehicle Compatibility
| Year | Make | Model | Details |
|---|---|---|---|
| 1997-2005 | Chevrolet | Blazer | Front Wheel Bearing |
| 1997-2004 | Chevrolet | S10 Pickup | Front Wheel Bearing |
| 1997-2005 | GMC | Jimmy | Front Wheel Bearing |
| 1997-2004 | GMC | Sonoma | Front Wheel Bearing |
| 1998-2000 | Isuzu | Hombre | Front Wheel Bearing |
| 1997-2001 | Oldsmobile | Bravada | Front Wheel Bearing |
10-year warranty for reliability and peace of mind.
3-7 days delivery, orders processed the next business day.
