MOOG 515096 - Chevrolet Silverado 1500 Front Wheel Bearing Hub Assembly 2007-2013
Regular price
$85.95
Regular price
$146.12
-41%
Sale price
$85.95
MOOG 515096 - Chevrolet Silverado 1500 Front Wheel Bearing Hub Assembly 2007-2013
The MOOG 515096 Front Wheel Bearing and Hub Assembly is designed as a direct-fit replacement for compatible 4WD and AWD applications. This pre-assembled hub unit features an integrated ABS sensor, 33 splines, 6 wheel studs, and a triangular 3-bolt mounting flange for straightforward replacement of the original front hub assembly.
Designed to restore smooth wheel rotation and proper hub operation, this complete assembly is supplied ready for installation on the compatible Cadillac and Chevrolet applications listed below.
Vehicle Fitment
| Year | Make | Model | Drive Type | Fitment Details |
|---|---|---|---|---|
| 2007-2014 | Cadillac | Escalade | AWD | Front Wheel Hub Assembly |
| 2007-2014 | Cadillac | Escalade ESV | AWD | Front Wheel Hub Assembly |
| 2007-2013 | Cadillac | Escalade EXT | 4WD | Front Wheel Hub Assembly |
| 2007-2013 | Chevrolet | Avalanche | 4WD | Front Wheel Hub Assembly |
| 2007-2013 | Chevrolet | Silverado 1500 | 4WD | New Body Style; 6-Stud |
| 2007 | Chevrolet | Silverado 1500 HD | 4WD | New Body Style; 6-Stud |
| 2007-2014 | Chevrolet | Suburban 1500 | 4WD | 6-Stud |
| 2007-2014 | Chevrolet | Tahoe | 4WD | 6-Stud |
Fitment Note: Please verify your vehicle's year, make, model, drivetrain, 6-stud configuration, and original hub specifications before ordering. Similar models may use different wheel hub assemblies depending on drivetrain and vehicle configuration.
Product Specifications
| Brand | MOOG |
| Part Number | 515096 |
| Product Type | Wheel Bearing and Hub Assembly |
| Position | Front |
| Drive Type | 4WD / AWD — Application Dependent |
| ABS Sensor Included | Yes |
| Wheel Stud Quantity | 6 |
| Spline Quantity | 33 |
| Flange Bolt Hole Quantity | 3 |
| Flange Shape | Triangular |
| Bolt Circle Diameter | 5.500 in / 139.7 mm |
| Brake Pilot Diameter | 3.087 in / 78.4 mm |
| Flange Diameter | 5.500 in / 139.7 mm |
| Flange Offset | 1.976 in / 50.2 mm |
| Hub Pilot Diameter | 3.087 in / 78.4 mm |
| Wheel Pilot Diameter | 77.7 mm |
| Quantity | 1PCS |
Reference Part Number
| Reference Type | Part Number |
|---|---|
| MOOG Part Number | 515096 |
Key Features
- Direct-Fit Design: Pre-assembled front wheel bearing and hub unit designed for compatible 4WD and AWD applications.
- Integrated ABS Sensor: Includes the ABS sensor required for compatible anti-lock braking system applications.
- Pre-Assembled Hub Unit: Wheel bearing and hub components are assembled into one unit for convenient replacement.
- Sealed Bearing Design: Helps protect internal bearing components against road dirt, moisture, and contaminants.
- 6-Stud Configuration: Designed for the compatible 6-stud vehicle applications listed in the fitment table.
- 33-Spline Design: Features a 33-spline configuration for compatible front drivetrain applications.
Package Contents
| Item | Part Number | Quantity |
|---|---|---|
| Front Wheel Bearing and Hub Assembly | 515096 | 1PCS |
Before You Buy
| Check | Requirement |
|---|---|
| Part Number | Confirm MOOG 515096 matches the required replacement hub |
| Installation Position | Front |
| Drivetrain | Confirm the required 4WD or AWD configuration shown in the fitment table |
| Wheel Studs | 6 Studs |
| Splines | 33 Splines |
| ABS | Confirm vehicle application uses the corresponding ABS-equipped hub assembly |
| Vehicle Configuration | Verify year, make, model, drivetrain, and application notes before purchase |
Installation Notes
- Verify vehicle fitment and drivetrain configuration before removing the original hub assembly.
- Compare the original hub's 6-stud pattern, 33-spline configuration, mounting flange, and ABS connection with the replacement part before installation.
- Clean the steering knuckle and mounting surface before installing the replacement hub.
- Route and connect the ABS sensor wiring correctly and keep the wiring away from moving or hot components.
- Tighten the axle nut, hub mounting bolts, brake components, and wheel fasteners according to the vehicle manufacturer's specified torque procedure.
- After installation, verify ABS operation and road-test the vehicle to confirm proper hub and braking system operation.
- Professional installation is recommended if you are unfamiliar with wheel bearing, hub, brake, or ABS system service.
Important: Vehicle applications can vary by drivetrain and production configuration. Always verify MOOG 515096, the 6-stud hub configuration, 33 splines, ABS connection, and your vehicle's exact fitment before installation.
