Rear Wheel Bearing Fit 2002-2005 Hyundai XG350, 2001 Hyundai XG300 Wheel Hub w/ABS, 5 Lugs, 512189 (2 Pack)
2001 Hyundai XG300
2002 2003 2004 2005 Hyundai XG350
Position:Driver(LH Left) or Passenger(RH Right) Side Rear
ABS Sensor Included: Yes
Wiring Harness Included: No
Number Of Mounting Bolts To Knuckle: 4
Number Of Lug Bolts Included: 5
Number Of Flange Bolts Included: 4
Driven Or Non-Driven: Non-Driven
ABS Ring Type: Tone
Number Of ABS Sensor Ring Teeth: 29
Lug Bolt Thread Size: M12-1.50
Total Hub Diameter (in): 5.826 Inch
Total Hub Diameter (mm): 148mm
Hub Centerbore Diameter (in): 4.5 Inch
Hub Centerbore Diameter (mm): 114.3mm
Total Hub Height (in): 5.334 Inch
Total Hub Height (mm): 135.5mm
Flange Diameter (in): 5.826 Inch
Flange Diameter (mm): 148mm
Flange Offset (in): 2.322 Inch
Flange Offset (mm): 59mm
Flange Shape: Rectangle
Flange Bolt Size (in): 1.437 Inch
Flange Bolt Size (mm): 36.5mm
Flange Bolt Thread Size: M10-1.25
Bearing Type: Ball
Outer Ring Width (in): 2.3 Inch
Inner Ring Width (in): 0.61 Inch
Hub Pilot Diameter (in): 2.59 Inch
Hub Pilot Diameter (mm): 65.9mm
