Moog 515125 Front Wheel Bearing Hub Assembly
Direct-fit hub & bearing unit for select Nissan/Infiniti 4WD/AWD applications. Built for quiet operation, correct ABS function, and long service life.
Fits 4WD/AWD models only | 6 Wheel Studs
Specifications
| Anti Lock Brake Sensor Included | Yes |
| Bolt Circle Diameter (IN) | 5.500 |
| Bolt Circle Diameter (MM) | 139.700 |
| Brake Pilot Diameter (MM) | 90.000 |
| Flange Bolt Hole Quantity | 3 |
| Flange Diameter (MM) | 171.000 |
| Flange Offset (MM) | 45.400 |
| Flange Shape | Triangle |
| Hub Pilot Diameter (MM) | 89.000 |
| Wheel Pilot Diameter (MM) | 77.700 |
| Wheel Stud Quantity | 6 |
Vehicle Fitment
Fits 4WD / AWD models only
| Make | Model | Year(s) | Drive | Position | Notes |
| INFINITI | QX56 | 2008–2010 | 4WD | Front (Left or Right) | 6-stud hub |
| NISSAN | Armada | 2008–2012 | 4WD / AWD | Front (Left or Right) | 6-stud hub |
| NISSAN | Titan | 2008–2012 | 4WD / AWD | Front (Left or Right) | 6-stud hub |
What’s in the Box
- 1 × Front Wheel Bearing Hub Assembly (Moog 515125)
Installation Notes
- Confirm 4WD/AWD and 6-stud configuration before ordering.
- Professional installation recommended; torque all fasteners to factory specs.
- After installation, road-test and recheck torque as required.
10-Year Warranty | Ships Next Business Day | Delivery 3–7 Business Days
