Rear Wheel Bearing Fit 2015-2019 Lexus NX200T-NX300H, 2006-2018 Toyota RAV4 Wheel Hub 5 Lug- 512374
Rear wheel bearing with ABS sensor for Lexus NX and Toyota RAV4 models. Steel construction with ball bearing for durability and smooth performance. Fits driven rear wheels with 5 lug bolts.
What's Included
- 1 Rear Wheel Bearing Hub (Part No. 512374)
- 5 Lug Bolts
- 5 Flange Bolts
- ABS Sensor Included
Product Specifications
- Position: Driver (LH) or Passenger (RH) Side Rear
- ABS Sensor: Yes
- Wiring Harness: No
- Mounting Bolts to Knuckle: 4
- Lug Bolts: 5
- Flange Bolts: 5
- Driven: Yes
- Number of Splines: 26
- ABS Ring Type: Encoder
- Total Hub Diameter: 5.35 Inch
- Hub Centerbore Diameter: 4.5 Inch
- Total Hub Height: 6.457 Inch
- Flange Diameter: 5.349 Inch
- Flange Offset: 2.549 Inch
- Hub Pilot Diameter: 2.99 Inch
- Flange Shape: Square
- Material: Steel
- Bearing Type: Ball
Vehicle Compatibility
| Year | Make | Model | Details |
|---|---|---|---|
| 2015-2017 | Lexus | NX200t, NX200t F Sport | Rear Wheel |
| 2018-2019 | Lexus | NX300 AWD, NX300 F Sport AWD | Rear Wheel |
| 2015-2019 | Lexus | NX300h | Rear Wheel |
| 2006-2018 | Toyota | RAV4 4WD, Adventure AWD, Hybrid Limited, Hybrid SE AWD, Hybrid XLE AWD, LE 4WD/AWD, Limited 4WD/AWD, Platinum AWD, SE 4WD/AWD, Sport 4WD, XLE 4WD/AWD | Rear Wheel |
10-year warranty included for reliability.
